204 Code Clones and Two Self-Loops: Dissecting Bevy's 97-Crate Engine with 67 AST Tools

We benchmarked all 67 prod-code AST tools against bevyengine/bevy: 661K lines of Rust, 97 crates, 204 exact code clones, 2 dev-dependency loops, and Bug #739 discovered and fixed in fast-sync.

bevyengine/bevy is celebrated as the flagship data-driven game engine in modern Rust. Its custom Entity Component System (ECS), compile-time system scheduling, and high-performance renderer have made it the darling of the Rust graphics community. But under the hood, Bevy is also a legendary stress test for compilers, IDEs, and developer laptops: 661,813 lines of Rust across 97 workspace crates and 98 Cargo manifests, heavily leaning on deep macro expansion, type reflection, and massive generic instantiations.

On a standard developer laptop, loading Bevy into rust-analyzer routinely consumes 10–25 GB of RAM, spins cooling fans to jet-engine levels, and stalls AI coding agents trying to parse cross-crate symbol graphs.

To see whether a cluster-backed remote code intelligence architecture can handle an engine of this scale with 0% local laptop CPU, we subjected bevy to our standardized 67-tool evaluation protocol of prod-code on our 32-core Linux build node (booster).

Here is what 67 AST analyzers found when dissecting Bevy.

1. Node Topology & Fast-Sync Ingestion

Syncing a 661K-line workspace across 3,044 files over a local network usually forces agents into sluggish Git clones or file-watcher thrashing. With prod-code, the checkout is projected into cluster memory via hash-watermarked differential sync:

Local Checkout:   /Users/alex09x/Documents/workspace/bevy-eval
Target Host:      booster (192.168.2.168:9400 / AMD EPYC 32-core, 134 GB RAM)
LAN Latency:      613.67 µs RTT
Rust Source Files: 1,917 (.rs)
Total Files:      3,044
Lines of Rust:    661,813 across 97 crates

Ingestion Telemetry

Initial Cold Sync: 3,044 files (81 MB) transferred and hydrated in 18.2s.
Warm Incremental Sync: 0 files updated in 0.0ms via manifest probe.
Remote Memory Footprint: rust-analyzer held Bevy’s whole 97-crate Salsa database in 3,773 MB RSS, expanding to 26,692 MB during whole-program reachability scans.
Local Laptop Load: Strictly 0.0% CPU, zero fan spin, zero battery drain.

2. Crate Topology & The Two Self-Loops

Using code_dependencies (Tool 4), we extracted Bevy’s full package dependency graph across 84 compiled library crates and 708 dependency edges:

⚡ prod-code Architecture & Dependency Graph Report
Scope: crates | Nodes: 84 | Dependencies: 708

🚨 CYCLES DETECTED: 2 circular dependency path(s) found:
  1. bevy_math -> bevy_math
  2. bevy_remote -> bevy_remote

The cycle detector flagged two direct dev-dependency self-loops: bevy_math -> bevy_math and bevy_remote -> bevy_remote. In Cargo workspaces, dev-dependencies can reference the crate itself for integration tests or benchmarks, but if tools fail to isolate dev-dependencies from regular builds, these cycles cause infinite recursion in topological compilation algorithms.

Coupling & Instability Metrics (Cₐ, Cₑ, I)

We calculated Robert C. Martin’s architectural coupling metrics:

Afferent Coupling (Cₐ): Number of crates depending on this crate (incoming edges / stability requirement).
Efferent Coupling (Cₑ): Number of crates this crate depends on (outgoing edges).
Instability Index (I = Cₑ / (Cₐ + Cₑ)): 0.0 = purely stable bedrock; 1.0 = volatile leaf.

Crate	Cₐ (Incoming)	Cₑ (Outgoing)	Instability (I)	Architectural Role
`bevy_reflect`	51	3	0.06	Type reflection & dynamic serialization bedrock
`bevy_ecs`	49	5	0.09	Entity-Component-System core data structures
`bevy_app`	46	6	0.12	Application lifecycle & plugin builder
`bevy_platform`	44	0	0.00	Pure leaf OS/runtime foundation
`bevy_math`	37	2	0.05	Linear algebra, curves, bounding volumes
`bevy_asset`	34	7	0.17	Asset server & loader pipelines
`bevy_utils`	31	1	0.03	Core utilities, hashing, tracing helpers
`bevy_derive`	27	1	0.04	Procedural derive macros
`bevy_camera`	24	14	0.37	Camera views & projections
`bevy_color`	23	3	0.12	Color spaces & conversions
`bevy_transform`	22	6	0.21	Transform hierarchies & propagation
`bevy_image`	21	8	0.28	Texture & image buffers
`bevy_log`	21	4	0.16	Tracing & logging integration
`bevy_mesh`	17	9	0.35	Mesh data & vertex layouts
`bevy_render`	14	23	0.62	Render pipelines & GPU abstractions

bevy_platform (Cₐ=44, Cₑ=0) is an absolute pure foundation crate with an instability index of 0.00. Meanwhile, bevy_reflect (Cₐ=51) serves as the single most critical structural bedrock of the engine, exceeding even bevy_ecs (Cₐ=49).

The 8-Module Circular Knot in `bevy_ecs`

Running Tarjan’s Strongly Connected Components (SCC) algorithm across module-level use crate:: paths inside crates/bevy_ecs/src revealed a massive circular knot:

Top-level modules in bevy_ecs: 17
Cyclic module SCC components in bevy_ecs: 1
  SCC 1 (8 modules): reflect, schedule, world, system, query, entity, component, resource

All 8 primary sub-modules of Bevy’s ECS mutually depend on one another. An edit to Entity or Component immediately cascades through World, Query, System, and Schedule.

3. The AST Clone Harvester: 204 Exact Clones

Using code_find_duplicates (Tool 5), prod-code scanned all 1,917 Rust files for duplicate token blocks ($\ge 10$ lines):

Type-1 Clones (Exact AST blocks): 204 clone groups (460 total instances).
Type-2 Clones (Structural clones with renamed identifiers): 633 clone groups (1,619 total instances).

Where Do the Clones Live?

Condition Evaluation Helpers: In crates/bevy_ecs/src/schedule/condition.rs, 10 identical blocks duplicate condition evaluation logic.
Benchmark Iteration Boilerplate: 8 benchmarks under benches/benches/bevy_ecs/iteration/ duplicate identical setup boilerplate across iter_simple.rs, iter_simple_foreach_sparse_set.rs, etc.
Primitive Reflection Trait Implementations: In crates/bevy_reflect/src/impls/core/primitives.rs, 14 occurrences of identical 10-line trait implementation blocks implement into_partial_reflect across scalar types.
Gizmo Drawing Pipelines: In crates/bevy_gizmos/src/primitives/dim3.rs, 19 structural clones implement drawing loops across 3D primitive types.

prod-code automatically generated recommendations to fold these blocks using code_extract_function, potentially saving thousands of lines of maintenance overhead.

4. Bug #739: The Hidden Cargo Directory Trap in Fast-Sync

During Step 9 of our evaluation protocol (prod-code check --path crates/bevy_app), the remote compiler check failed with target resolution errors:

error: can't find example `computed_states` at path `/.../bevy-eval/examples/state/computed_states.rs`
error: can't find example `custom_transitions` at path `/.../bevy-eval/examples/state/custom_transitions.rs`
error: can't find example `states` at path `/.../bevy-eval/examples/state/states.rs`
error: can't find example `sub_states` at path `/.../bevy-eval/examples/state/sub_states.rs`
error: could not compile due to 4 previous target resolution errors

All four example files existed locally in the checkout, but were absent on the build node!

Root Cause Analysis

In crates/prod-code-mcp/src/sync.rs, the relevance filter is_relevant_code_or_manifest_file excluded non-code/cache directories:

if !under_code_dir
    && matches!(
        s.as_ref(),
        "target" | "node_modules" | "data" | "state" | "artifacts" | "research" | ...
    )
{
    return false;
}

However, under_code_dir only checked crates, packages, src, internal, pkg, cmd, api, Sources, Tests, include, lib. Standard Cargo directories—examples, example, tests, test, benches, bench—were omitted!

When fast-sync encountered examples/state/computed_states.rs, under_code_dir was false. When it reached the next directory component (state), it matched the blacklist and silently dropped the entire directory!

The Fix & Verification

Reported as GitHub Issue #739 via prod-code report-issue.
Expanded under_code_dir in crates/prod-code-mcp/src/sync.rs:

if matches!(
    s.as_ref(),
    "crates"
        | "packages"
        | "src"
        | "internal"
        | "pkg"
        | "cmd"
        | "api"
        | "Sources"
        | "Tests"
        | "include"
        | "lib"
        | "examples"
        | "example"
        | "tests"
        | "test"
        | "benches"
        | "bench"
) {
    under_code_dir = true;
}

Bumped RELEVANCE_VERSION to 10 to trigger automatic rescan of affected directories.
Added regression test cargo_examples_and_tests_under_state_and_data_are_relevant.
Committed (ff6fcad) and deployed. Switched the local client build to an unoptimized dev debug profile, cutting compile times to 2 seconds.
Re-ran prod-code check: all example targets synced and passed in 0.8s.

5. Semantic & Structural AST Search

Querying 661K lines of Rust without generating compiler-level AST indexes results in slow, noisy grep searches.

Semantic Natural Language Search (`code_search`)

Searching for spawn entity with bundle components indexed and ranked 45,503 declarations across 1,913 files in 492 ms:

10 hit(s) for `spawn entity with bundle components` in 492 ms (45,503 declarations, 1,913 files)

 1. [function] Commands::spawn  crates/bevy_ecs/src/system/commands/mod.rs:283
    pub fn spawn<T: Bundle>(&mut self, bundle: T) -> EntityCommands<'_>
    - [`spawn_empty`](Self::spawn_empty) to spawn an entity without any components.

 2. [function] RelatedSpawner::spawn  crates/bevy_ecs/src/relationship/related_methods.rs:583
    pub fn spawn(&mut self, bundle: impl Bundle) -> EntityWorldMut<'_>
    Spawns an entity with the given `bundle` and an `R` relationship...

 3. [function] World::spawn  crates/bevy_ecs/src/world/mod.rs:1243
    pub fn spawn<B: Bundle>(&mut self, bundle: B) -> EntityWorldMut<'_>

Structural AST Pattern Search (`code_structural_search`)

We searched for all occurrences of the AST pattern $x.is_empty():

⚡ prod-code Structural AST Search: `$x.is_empty()`
────────────────────────────────────────────────────
510 match(es) in 223 file(s) (1,917 scanned in 374.56 ms)

In 374 ms, prod-code scanned 1,917 Rust files and extracted 510 exact syntax matches across 223 files with bound meta-variables.

6. Type Hierarchy & The 28 Traits of `Entity`

Bevy’s central currency is the Entity struct. We used code_supertypes (Tool 14) and code_hover (Tool 15) to inspect its exact representation:

📍 Definition: crates/bevy_ecs/src/entity/mod.rs:447:12

pub struct Entity {
    #[cfg(target_endian = "little")]
    index: EntityIndex,
    generation: EntityGeneration,
    #[cfg(target_endian = "big")]
    index: EntityIndex,
}

Trait Hierarchy Discovery

Entity implements 28 distinct traits across standard library and ECS contracts:

QueryData, ReadOnlyQueryData, SingleEntityQueryData, ContiguousQueryData, ArchetypeQueryData, IterQueryData, ReleaseStateQueryData
WorldQuery, WorldEntityFetch
RelationshipSourceCollection, MapEntities, SparseSetIndex, ContainsEntity, EntityEquivalent
FromTemplate, Reflect, Serialize, Deserialize
Clone, Copy, Debug, Display, Eq, PartialEq, Ord, PartialOrd, Hash, FromStr

Using code_references (Tool 10), prod-code traced 3,160 incoming references to Entity across all 97 crates in 2.57 seconds.

Call Graph Navigation (`code_callers` & `code_callees`)

code_callers on App::run: identified 300+ incoming caller sites across examples, benchmarks, and tests in 1.1s.
code_callees on App::run: identified its 5 core outgoing dispatch targets (tracing::Span::entered, App::is_building_plugins, core::mem::replace, Box::new, App::empty).

7. Program Slicing: Bounding Massive ECS Structures

When an LLM coding agent inspects a symbol in a 661K-line codebase, reading entire files consumes the context window. code_slice (Tool 8) computes minimal forward/backward data-flow closures.

Slicing `Entity` (99% Reduction)

$ prod-code slice crates/bevy_ecs/src/entity/mod.rs --line 447 --depth 1
BOUNDED slice of `Entity`: 3 item(s), 371 bytes from 66,477 bytes of source (99% smaller)

The slice trimmed 66 KB of source down to 371 bytes containing only EntityIndex, EntityGeneration, and Entity.

Cross-Crate Slicing `App` (99% Reduction)

$ prod-code slice crates/bevy_app/src/app.rs --line 85 --depth 1
BOUNDED slice of `App`: 4 item(s), 825 bytes from 100,872 bytes of source (99% smaller)

The slice walked across crate boundaries, returning App and SubApps from bevy_app, and pulling in ErrorHandler from crates/bevy_ecs/src/error/handler.rs.

8. Guarded AST Refactorings & Integrity Loop

We tested semantic transformations under our strict 5-step integrity loop (Execute → Diff → Compile → Test → Revert).

Multi-Callsite Semantic Rename

We renamed is_building_plugins to is_any_subapp_building_plugins using code_rename:

--- a/crates/bevy_app/src/app.rs
+++ b/crates/bevy_app/src/app.rs
@@ -156,7 +156,7 @@ impl App {
     pub fn update(&mut self) {
-        if self.is_building_plugins() {
+        if self.is_any_subapp_building_plugins() {
             panic!("App::update() was called while a plugin was building.");
         }
@@ -185,7 +185,7 @@ impl App {
     pub fn run(&mut self) -> AppExit {
-        if self.is_building_plugins() {
+        if self.is_any_subapp_building_plugins() {
             panic!("App::run() was called while a plugin was building.");
         }
@@ -297,7 +297,7 @@ impl App {
-    pub(crate) fn is_building_plugins(&self) -> bool {
+    pub(crate) fn is_any_subapp_building_plugins(&self) -> bool {
         self.sub_apps.iter().any(SubApp::is_building_plugins)
     }

prod-code renamed the definition and updated all call-sites in 2.57 seconds. We validated compilation and ran 20 unit tests remotely via prod-code exec (100% passed), then cleanly reverted with git checkout -- ..

Safe-Delete Guard Refusal

When attempting to delete Entity via code_safe_delete:

safe delete refused: prodCode/safeDelete failed: 3160 usage(s) reference this item; delete refused:
crates/bevy_transform/src/helper.rs:6:14
crates/bevy_ecs/src/query/filter.rs:5:24
crates/bevy_ecs/src/query/mod.rs:118:35
… 3140 more

The semantic guard refused the deletion and listed all 3,160 incoming usages.

Invert Boolean Predicate

Using code_invert_boolean, we inverted any_spawned to is_empty_spawned in crates/bevy_ecs/src/entity/mod.rs:

-    pub fn any_spawned(&self) -> bool {
-        self.meta.iter().any(|meta| meta.location.is_some())
-    }
+    pub fn is_empty_spawned(&self) -> bool {
+        !(self.meta.iter().any(|meta| meta.location.is_some()))
+    }

The analyzer verified the negation in scope with 0 compiler errors.

Dead-Code Orphan Prune Guard

Running prod-code prune flagged two unreferenced items in benchmarks:

the analyzer rejects the result:
  not all trait items implemented, missing: `fn from` [E0046] (benches/benches/bevy_ecs/entity_cloning.rs:229:6)
nothing was written

prod-code detected that removing fn from would break the impl From<FilterScenario> for String trait implementation, and automatically aborted the change!

9. Speculative Synthesis, RAM Validation & Shadow Runs

In-Memory Pre-Flight Validation (`code_validate_edit`)

We injected a deliberate type error into an in-memory buffer of crates/bevy_app/src/app.rs:

app.sub_apps.main.update_schedule = "invalid string type";

Without saving anything to disk, prod-code validate evaluated the buffer in server RAM against the live Salsa database:

crates/bevy_app/src/app.rs: 1 error(s), 1 warning(s)
  (131 diagnostic(s) the file already had before this edit are not counted)
  error: expected Option<Interned<dyn ScheduleLabel>>, found &'static str [E0308] (crates/bevy_app/src/app.rs:111:45)
[prod-code] analysed in 10.66s

The analyzer caught the exact type mismatch in 10.66s while ignoring 131 pre-existing baseline warnings.

Typed Builder Synthesis (`code_generate_fixture`)

We synthesized a typed builder fixture for EntityLocation:

$ prod-code fixture EntityLocation --builder --path crates/bevy_ecs/src/entity/mod.rs
builder `EntityLocationBuilder` for `EntityLocation` (4 fields), declared in crates/bevy_ecs/src/entity/mod.rs:1278-1299;

verified: the analyzer checked it in the scope of the declaration: 0 errors
nothing was written

prod-code generated EntityLocationBuilder with 4 fields, typed setters, and validation errors, fully verified in AST context.

Expression Synthesis (`code_propose_expression`)

Querying prod-code propose-expression crates/bevy_app/src/app.rs 301 bool synthesized 22 ranked in-scope boolean expressions:

!_bevy_app_run_span (Confidence: 70%)
!overall_plugins_state (Confidence: 70%)
app.is_empty() (Confidence: 65%)

Multi-Hypothesis Shadow Runs (`code_shadow_run`)

We submitted two concurrent hypotheses to prod-code shadow-run to test competing patches in isolated copy-on-write RAM overlays on the cluster:

$ prod-code shadow-run spec.json -- cargo check -p bevy_app
  candidate_valid   exit 0     in 6.4s  ~0 changed line(s)  <- winner
  candidate_broken  exit 101   in 6.4s  ~2 changed line(s)
winner: candidate_valid
--- candidate_broken output ---
error[E0425]: cannot find type `BrokenNonExistentType` in this scope

Both hypotheses ran in parallel on dedicated cluster cores, selecting the winning candidate in 6.4 seconds without touching the local working tree.

10. Remote 32-Core Build, Lint & Bench via `prod-code exec`

All build, test, and benchmark runs executed remotely on node booster via prod-code exec, returning structured execution metrics:

# Remote Cargo Check
$ prod-code exec -- cargo check -p bevy_app
Finished `dev` profile in 0.14s
[prod-code exec] exit 0 in 0.8s (server 0.4s, cpu 0.1s user, peak 101 MB)

# Remote Unit & Doc Tests (88 tests)
$ prod-code exec -- cargo test -p bevy_app
running 54 tests ... 54 passed; 0 failed
Doc-tests bevy_app ... 34 passed; 0 failed; 1 ignored
[prod-code exec] exit 0 in 1.6s (server 1.2s, cpu 1.0s user, peak 308 MB)

# Remote Clippy
$ prod-code exec -- cargo clippy -p bevy_app -- -D warnings
Finished `dev` profile in 0.17s
[prod-code exec] exit 0 in 0.8s (server 0.3s, cpu 0.1s user, peak 101 MB)

# Remote Release Benchmark Suite
$ prod-code exec -- cargo test -p bevy_app --release -- --nocapture
Finished `release` profile in 16.58s
running 54 tests ... 54 passed; 0 failed
Doc-tests bevy_app ... 34 passed; 0 failed; 1 ignored
[prod-code exec] exit 0 in 18.0s (server 17.6s, cpu 13.2s user, peak 403 MB)

Conclusion & Evaluation Summary

Benchmark Suite	Evaluated Scope	Outcome & Latency
1. Node Topology & Sync	661K lines, 3,044 files across 97 crates	18.2s cold sync (81 MB), 613 µs LAN RTT, 0% laptop CPU
2. Architecture & DAG	84 crates, 708 edges, 17 ECS modules	2 circular dev-loops detected; 8-module circular knot in `bevy_ecs`
3. AST Clone Harvester	1,917 files scanned	204 Type-1 and 633 Type-2 clone groups detected
4. Fast-Sync Bug Fix	Issue #739 in `is_relevant_code_or_manifest_file`	Bug identified, reported, fixed in `sync.rs` (v10), deployed in 1 turn
5. Semantic AST Search	45,503 declarations in 1,913 files	492 ms intent query; 374 ms structural AST pattern match (510 hits)
6. Navigation & Supertype Hierarchy	`Entity` & `Plugin` across all crates	`Entity` implements 28 traits; 3,160 usages traced in 2.57s
7. Program Slicing	`Entity` & `App` symbol bounds	99% context reduction (66 KB → 371 B; 100 KB → 825 B)
8. Semantic Guards	Multi-callsite rename & safe-delete	Rename in 2.57s; safe-delete refused on 3,160 usages; prune guarded
9. Synthesis & Pre-flight	In-memory RAM typecheck & shadow runs	RAM caught `E0308` in 10.66s (0 disk I/O); shadow run picked winner in 6.4s
10. Remote Execution	32-core AMD EPYC on `booster`	Check in 0.8s, 88 tests in 1.6s, Clippy in 0.8s, Release in 18.0s

By shifting language server databases, AST compilation, and test execution to a cluster node via prod-code, even monolithic 661,000-line Rust codebases like Bevy can be navigated, sliced, and refactored by AI coding agents with zero local latency and zero laptop battery drain.
